Magnesite is the main raw material of magnesia brick, and its basic component is MgCO3, which is calcined at high temperature and then crushed to a certain particle size to become sintered magnesia. Magnesia is widely used as furnace mending material and ramming material. Magnesia with few impurities (ω(CaO)<2.5%, ω(SiO2)<3.5%) is used as raw material for manufacturing magnesia bricks.
Magnesia brick belongs to basic refractory, which has strong resistance to alkaline slag, but can't resist the erosion of acidic slag. At 1600℃, it can react with silica brick, clay brick and even high alumina brick. The fire resistance of magnesium brick is above 2000℃, but its softening point under load is only 1500~1550℃. Moreover, the temperature interval from softening to 40% deformation is very small, and the thermal stability of magnesia brick is poor only at 30~50℃, which is an important reason for the damage of magnesia brick. In heating furnace and soaking pit, magnesia brick is mainly used to pave the bottom surface layer and the bottom wall of soaking pit, which can resist the erosion of iron oxide scale.
Magnesia raw materials are crushed into granular materials and powder materials. After proportioning according to a certain ratio, they are mixed with binder to form pug, and then the fired magnesia brick is made by molding, drying and firing. The firing temperature of ordinary magnesia brick is generally 1500~1650℃, while that of high purity magnesia brick is as high as 1700~1900℃. The production process of chemical bonded magnesia brick is basically the same, except that it can be made into unfired magnesia brick by chemical bonding agent without high-temperature firing, and only by proper low-temperature heat treatment.
Our company has brand-new bricks and second-hand bricks, and the prices are different. We can quote according to the customer's needs. The page price is for reference, and the specific price will be communicated with you in detail by our sales manager! Welcome to consult and buy!
| Project | Index | ||||||||
| M-98 | M-97A | M-97B | M-95A | M-95B | M-93 | M-91 | M-89 | M-87 | |
| MgO /% ≥ | 97.5 | 97 | 96.5 | 95 | 94.5 | 93 | 91 | 89 | 87 |
| SiO2/% ≤ | 1. 0 | 1.2 | 1.5 | 2.0 | 2.5 | 3.5 | － | － | － |
| CaO/% ≤ | － | － | － | 2.0 | 2.0 | 2.0 | 3.0 | 3.0 | 3.0 |
| Apparent porosity/％ ≤ | 16 | 16 | 18 | 16 | 18 | 18 | 18 | 20 | 20 |
| Volume density/（g/cm3） | 3.00~3.20 | 3.00～3.20 | 2.95～3.15 | 2.90～3.10 | 2.85～3.05 | ||||
| High pressure resistance at room temperature degree/ MPa ≥ | 60 | 50 | |||||||
| 0.2MPa Starting temperature of softening under load/℃ ≥ | 1700 | 1650 | 1620 | 1560 | 1550 | 1540 | |||
| Heating permanent line change 1650℃×2h ％ | -0.2～0 | -0.2～0 | -0.3～0 | -0.4～0 | -0.5～0 | -0.6～0 | - | ||
Our company is a global glass technology equipment engineering system integration service provider. Provide "one-stop" system integration services for glass engineering R&D design, engineering construction, equipment manufacturing, commissioning and production operation. In terms of photovoltaic rolled glass, small and medium float glass, water glass and light industry energy-saving glass, all oxygen and electric fluxing glass technology, the company has its own patented technology.
Q: Are you a manufacturer or a trading company?
A: We are a manufacturer, specializing in providing "one-stop" system integration services for R&D design, engineering construction, equipment manufacturing, commissioning and production operation of glass engineering.
Q: How long is your delivery time?
A: As we are an engineering manufacturer, we need to go to your place to inspect, design and build glass furnaces, which will take a long time. Specifically, our sales manager will communicate with you in detail.
Q: Do you arrange customers visiting your factory?
A: Welcome to visit at any time! But it's best to make an appointment with our sales manager, who needs to arrange everything for you to come to the factory.
Q: What is your terms of payment?
A: We support L/C,T/T payment. Payment terms: 30% in advance, 30% of the contract amount before delivery, 30% of the contract amount after cold acceptance, 5% of the contract amount after hot acceptance, and 5% of the contract amount during the warranty period.
Q: How can you guarantee quality?
A: Our glass kilns are engineering products, all of which are designed and built by our company sending professionals to you. When the engineering project is finished, a series of work such as commissioning will be carried out on site, and there will be training and technical support, after-sales service, etc. All products have a one-year warranty period. Please feel free to cooperate with us.
