Customizable
One year warranty after project completion
By sea
The technological process of glass fiber production line determines that more equipment is needed, which generally includes:
Automatic feeding system
Glass melting furnaces
Solution fiberizing centrifuge
Collect fibers, collect cotton and side walls.
White cotton pressure coiling system
Curing furnace
Cooling conveyor
Longitudinal cutting conveyor
Edge-breaking conveyor
Crosscutting machine
Automatic felt rolling machine
PLC full-automatic control system
1.Batch preparation:
Batch production line consists of pneumatic conveying and feeding system, electronic weighing system and pneumatic mixed conveying system.
2. Glass melting:
The qualified batch delivered to the kiln head silo is fed by the closed screw at both sides of the unit kiln and put into the kiln head, and melted into high-quality molten glass at 1550~1600℃. After being clarified and homogenized, the molten glass flows from the melting part to the main channel, and then flows into the liquid trough through the operation channel for drawing the platinum-rhodium alloy bushing.
3. Fiber forming:
Fiber forming is the process of making glass liquid into glass fiber precursor. The molten glass flowing out of the multi-row hole drawing bushing is drawn and molded into fibers by a wire root cooler and a wire drawing machine at a high speed. The formed monofilament is coated by a monofilament oiler.
4. Preparation of wetting agent:
The wetting agent is a necessary coating for the production and processing of glass fiber, which can protect the fiber, bundle monofilaments, prevent .369 from accumulating static charges on the surface of the fiber, provide the fiber with the characteristics needed for further processing and application, and make the fiber and substrate have good surface properties.
5. Processing of glass fiber products:
Direct yarn, the precursor cake wound by the automatic bobbin-changing wire drawing machine, is dried (heated by steam) in a tunnel drying furnace, peeled, packaged, put in storage and delivered from the factory.
Chopped strand: chopped strand cut online after fiber forming, dried and screened by steam, packaged, put in storage and delivered from the factory.
This is a glass melting furnace, Glass fiber production line. The glass melting furnace and supporting production line sold by our company are mainly customized according to your required output and plant area, and the price is not fixed. According to your request and the on -the-spot investigation of our dispatched personnel, our sales manager will provide you with a specific quotation.
Our company is a global glass technology equipment engineering system integration service provider. Provide "one-stop" system integration services for glass engineering R&D design, engineering construction, equipment manufacturing, commissioning and production operation. In terms of photovoltaic rolled glass, small and medium float glass, water glass and light industry energy-saving glass, all oxygen and electric fluxing glass technology, the company has its own patented technology.
Q: Are you a manufacturer or a trading company?
A: We are a manufacturer, specializing in providing "one-stop" system integration services for R&D design, engineering construction, equipment manufacturing, commissioning and production operation of glass engineering.
Q: How long is your delivery time?
A: As we are an engineering manufacturer, we need to go to your place to inspect, design and build glass furnaces, which will take a long time. Specifically, our sales manager will communicate with you in detail.
Q: Do you arrange customers visiting your factory?
A: Welcome to visit at any time! But it's best to make an appointment with our sales manager, who needs to arrange everything for you to come to the factory.
Q: What is your terms of payment?
A: We support L/C,T/T payment. Payment terms: 30% in advance, 30% of the contract amount before delivery, 30% of the contract amount after cold acceptance, 5% of the contract amount after hot acceptance, and 5% of the contract amount during the warranty period.
Q: How can you guarantee quality?
A: Our glass kilns are engineering products, all of which are designed and built by our company sending professionals to you. When the engineering project is finished, a series of work such as commissioning will be carried out on site, and there will be training and technical support, after-sales service, etc. All products have a one-year warranty period. Please feel free to cooperate with us.
